Lopi • Lopi Fireplace Inserts

Radiant Plus Medium GSB

Propane Fireplace Insert

Times Square face

About the Radiant Plus Medium GSB

The Radiant Plus Medium GSB gas insert provides comforting radiant heat plus natural convection to living spaces up to 1,250 square feet, featuring a 309 square inch ceramic glass fireview and an energy-saving GreenSmart Basic control. The on-demand ignition pilot lights when heat is called for and turns off automatically to conserve fuel. It delivers a beautiful Dancing-Fyre display and keeps running on battery backup during a power outage.

Specifications

Heating Area: Up to 1,250 sq ft
BTU Output: 13,000 to 25,000 BTU/hr (NG and LP)
Efficiency: 86.98% (NG) / 89.03% (LP), steady state
Dimensions (H x W x D): 19.5 in x 26.5 in x 14.875 in
AFUE: 80.3% (NG) / 79.5% (LP)
Glass Viewing Area: 309 sq in, ceramic glass
Convection Fan: Optional, 100 CFM
Venting: Direct vent: 3 in exhaust and 3 in intake liners up the existing chimney (7 in minimum flue)
Fits: Masonry or factory-built (metal) wood-burning fireplaces
Minimum Fireplace Opening: 19.75 in H x 27 in W x 15 in D, 17.25 in wide at the back (13.75 in D with the panel trim)
Surround Panels: Optional: Small 38 x 25 in or Large 40 x 28.5 in (W x H); not needed with the Universal face
Hearth: Hearth extension not required (1.25 in with the panel trim)
Electrical: 120 V outlet with AA battery backup for power outages; optional blower 120 V, 0.55 A max
Installation: Bedroom and mobile home approved

Manuals & Documents

Manufacturer documents from Travis Industries. Each opens in a new tab.
