Lopi • Lopi Fireplace Inserts

658 Live Fire Deluxe

Propane Fireplace Insert New for 2026

Times Square face

About the 658 Live Fire Deluxe

The 658 Live Fire Deluxe is Lopi's newest gas insert, built around Live Fire technology: flames emerge naturally from within the logs for unmatched realism, movement, and glow. It has the largest fire view in its class, with 581 square inches of viewing area, yet fits fireplace openings as small as 34 inches. It puts out up to 39,000 BTU/hr on natural gas and 37,500 on propane, with your choice of Fir or Birch logs. Made in the USA.

Specifications

Heating Area: Up to 2,000 sq ft (NG) / 1,800 sq ft (LP)
BTU Output: 17,000 to 39,000 BTU/hr (NG) / 13,500 to 37,500 BTU/hr (LP)
Efficiency: 85.79% (NG) / 83.43% (LP), steady state
Dimensions (H x W x D): 23.75 in x 33.25 in x 17.125 in
Weight: 160 lbs
Glass Viewing Area: 581 sq in, ceramic glass
AFUE: 75.2% (NG) / 77.4% (LP)
Convection Fan: 180 CFM, standard
Accent Lights: Overhead and Ember-Glo
Venting: Co-linear direct vent through the existing chimney
Fits: Masonry or factory-built (metal) wood-burning fireplaces
Minimum Fireplace Opening: 24 in H x 34 in W x 17.5 in D (16.25 in D with panel trim)
Surround Panels: 42 x 30.5 in or 44 x 34 in
Hearth: No non-combustible hearth required in front of the insert
Electrical: 120 V, 1.8 A (blowers)
Installation: Bedroom and mobile home approved

Manuals & Documents

Manufacturer documents from Travis Industries. Each opens in a new tab.
